RESmart GII T-25A Auto BiPAP

1,080.00

The Resmart GII BiPAP System 25A is an auto bi-level device, ideal for sleep apnea patients experiencing difficulties adjusting to a fixed-pressure CPAP device. Inside the GII BiPAP are advanced auto bi-level air generators with two different, adjustable pressures. If you are looking for a reliable and durable auto BiPAP for a more comfortable therapy, then the GII is probably one of the best solutions you can find on the market.





SKU: TT0110 Categories: , Tags: , , , , ,
Description

Description

RESmart GII BPAP System T-20A

The RESmart GII BiPAP T-20A is an auto bi-level solution for patients with respiratory insufficiency. This auto bi-level device is specifically engineered by 3B Medical to maximize patient-device synchrony. It tracks events on a breath-by-breath basis to ensure ultra-precise amount of bi-level pressure while guaranteeing your comfort throughout the night.

Features

  • Real time monitoring: Tidal Volume (Vt), Respiratory rate (Res Rate), Minute ventilation (Min Vent), Leakage (Leak);
  • Quick and easy operation;
  • Slow and gentle Ramp;
  • Innovative tracking technology for accurate and comfortable therapy;
  • Unique sensitivity settings ensure better comfort during individual therapy;
  • Auto on/Auto off function;
  • Power off alert;
  • Tube & mask disconnected alert;
  • Automatic leakage and altitude compensation;
  • Multi-language system
  • SpO2 Kit: Blood oxygen saturation and pulse rate display.



ECO Smart Technology

The ECO Smart heating system boasts an innovative dual water chamber design providing optimum humidity and temperature during therapy. ECO Smart delivers the optimized humidity level through the heating chamber, while ensuring real time compensation and water quantity control throughout the night. This smart technology will also help you keep the water bills low thanks to its high efficiency rating.

3.5-inch Color LCD Display

The LCD color display of the RESmart GII shows rea-time pressure and flow wave data.

Easy data access whenever you need it

With RESmart GII and it’s built-in iCode and SD card records you can viewed and evaluate your sleep apnea treatment using the RESmart PC software or BMC+ iCode smart phone App

Ti Min/Ti Max Ensure inspiration time

Ti Min/Ti Max feature for more effective treatment compared to other competitive bi-level devices of the same class.



iCode II

  • Compliance Data is encoded by QR code
  • Google play and APP store apps are available
  • Dynamic parameters adjustment
  • Multiple data retrieval (SD Card/ iCode II/ WiFi)




Warranty
2-Year Manufacturers Warranty.




Technical specifications

Technical specifications

ModesCPAP, S, Auto
Max therapy pressure25 cmH2O
Display3.5 inch LCD
Dimensions170 х 196 х 118 mm
Weight< 1.5 kg
Operating temperature5°C to 35°C
Operating humidity15% to 93%
Atmospheric Pressure760 to 1060 hPa
SD Card4 GB
Power consumption100 – 240 V AC, 50/60 Hz, 2.0 A max
Type of Protection Against Electric ShockClass II
Degree of Protection Against Electric ShockType BF Applied Part
Degree of Protection Against Ingress of WaterIP22
Pressure RangeIPAP: 4.0 ~ 25.0 cm H2O (only applies to T-25S, T-25A, T-25T);
EPAP: 4.0 ~ 25.0 cm H2O (only applies to T-25S, T-25A, T-25T, T-30T); in 0.5 cm H2O increments.
CPAP Mode: 4.0 ~ 20.0 cm H2O
Pressure Display Accuracy± (0.8 hPa + 4%)
Static Pressure Stability± 0.5 hPa
Ramp0 to 60 minutes
Sound Pressure Level<30 dB, when device working at pressure of 10 hPa
SpO2Range: 0-100%
The margin of error for SpO2 between 70% and 100% is ±3%. No strict accuracy requirements for SpO2 below 70%.
Pulse RateRange: 40-240 bpm
Margin of Error: ± 3%
WavelengthsRed: 663 nanometers
Infrared: 890 nanometers
Maximal Optical Output PowerLess than 1.5 mw maximum average
TubeLength: 6 ft. (1.83m)
Heater Settings1 to 5 (95 to 167°F/ 35 to 75°C)
Maximum Operating Pressure30 hPa
Pressure Drop with Humidifier< 0.4 hPa at 60 LPM flow
Humidifier PerformanceHumidity Output: No less than 10 mg H2O/L
Environmental Conditions: Maximum airflow, 35°C, 15% relative humidity
Maximum Delivered Gas Temperature< 43°C
Warranty2 Years
Downloads

Downloads

User manual

FAQ

FAQ

Q. What is a BiPAP device used for?
A. A BiPAP device is primarily used in sleep apnea treatment, respiratory conditions, and lung disease.

Q. Where are RESmart devices manufactured?
A.
The RESmart CPAP and BiPAP devices by BMC Medical are manufactured in China. Headquartered in Beijing, China, BMC Meical is the leader in the development of home respiratory care devices in China.

Q. What are the main benefits of using a mid-range RESmart CPAP device instead of a higher-range model?
A. The RESmart respiratory care devices such as the GII are often preferred by customers looking for reliability, quiet operation and simplicity of settings – all without breaking the bank.

Q. Does the RESmart GII BiPAP come with documentation in languages other than English?
A. Yes. You can download the documentation in a language other than English from the BMC website.
